BestScope Scanpro-120 Digital Pathological Slide Scanner

  • Manufacturer

1.00 E£ 1.00 E£ 1.0 EGP

1.00 E£

This combination does not exist.

Add to Cart Request a quote

Scanpro-120 Digital pathological slide scanner is actually an automatic microscope, it can be loaded with 120pcs slides at a time (or a single slide can be loaded quickly manually). The instrument can get high-precision, high-quality panoramic digital slide images. The professional 3CCD line scan digital camera ensure more natural and accurate color reproduction and high-definition images. The instrument is simple and easy to use, reliable and…
Model: Scanpro-120 | Capacity: 120 slides | Lighting: LED | Scanning Mode: Line scanning | Acceptable Slides: 1x3 inch/2x3 inch | Magnification: 20X/40X | Resolution: 0.5μm/pixel(20X), 0.25μm/pixel(40X) | Focusing: Automatic/ Manual


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Scanpro-120 Digital Pathological Slide Scanner

Scanpro-120 Digital pathological slide scanner is actually an automatic microscope, it can be loaded with 120pcs slides at a time (or a single slide can be loaded quickly manually). The instrument can get high-precision, high-quality panoramic digital slide images. The professional 3CCD line scan digital camera ensure more natural and accurate color reproduction and high-definition images. The instrument is simple and easy to use, reliable and easy to maintain. With the pathology management system software, digital slides are associated with the clinical sighting, general examination and other information as one, which makes the diagnosis more convenient and timely, it also can be used for remote pathological diagnosis.Scanpro-120 is used for digitizing large batches of slides, which helps to set up a digital slides database.

Key Details

ModelScanpro-120
Capacity120 slides
LightingLED
Scanning ModeLine scanning
Acceptable Slides1x3 inch/2x3 inch
Magnification20X/40X
Resolution0.5μm/pixel(20X), 0.25μm/pixel(40X)
FocusingAutomatic/ Manual

Feature

1.High-volume slides fast processing, 120pcs slide just with one click.

2.Magnetic levitation non-contact motor drive stage ensures stable and quiet scanning.

3.Nanoscale level positioning accuracy.

4.Suitable for large hospitals and research institutes.

5.High quality line scanning 3CCD camera, ensures image quality adequate for diagnosis.

6.No need to watch over after one click operation.

7.On-line image browse for diagnosis and report.

Application

Scanpro-120 Digital pathological slide scanner is an ideal instrument for big hospitals and research institutes. It can be widely used in medical and sanitary establishments, such as hospitals, clinics, laboratories, medical academies, colleges, universities and related research centers for diagnosis or research. It also can be used in biological, pathological, histological, bacterial, immune, pharmacological, life science and genetic fields.

Specification

Item

Specification

Scanpro-120

Acceptable Slides

1×3 inch/2×3 inch

●

Capacity

120 slides

●

Lighting

LED

●

Scanning Mode

Line scanning

●

Objective Lens

Olympus Uplan apochromatic objective lens

●

Movement Control

Linear magnetic axis motor control

●

Magnification

20X/40X

●

Resolution

0.5μm/pixel(20X), 0.25μm/pixel(40X)

●

Scanning Speed

40sec/slide(20X, 15mmx15mm area)

100sec/slide(40X, 15mmx15mm area)

●

Z-stack Scan

Yes

●

Focusing

Automatic/ Manual

●

Precise Identification

Yes

●

Label Identification

Bar code/QR

●

Image Format

JPEG/JPEG2000/BMP/TIFF

●

Suggest Work Station

CPT: Intel Core I7 or above

Hard Disk: 1TB or above

Memory: 16G or above

Monitor: 24inch or above

○

Note: ● Standard Outfit, ○ Optional

Specifications for BestScope Scanpro-120 Digital Pathological Slide Scanner

Manufacturer BestScope
