BOECO Rotary Evaporator RVO 400 SD
BOECO Rotary Evaporator RVO 400 SD The RVO 400 SD conforms to the CE mark and all relevant EC standards and DIN norms and has been manufactured under ISO 9001:2000
With digital display and control
Water or oil bath
Motorized lif
Build in vacuum controler
Variable inclination angle of evaporating flask
With vertical or diagonal condenser
fitted and designed for control and communication by PC
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Technical details
| Receiving flasks: | 100 - 2000 ml |
| Evaporating flasks: | 20 - 4000 ml |
| Rotation speed: | 0 - 280 rpm |
| Bath temperature: | max. 100 °C for water filling; max. 180 °C for oil filling |
| Regulation accuracy: | ± 1 °C up to 100 °C; ± 3 °C up to 180 °C |
| Pressure measurement: | absolute |
| Pressure difference: | adjustable 1-500 mbar. |
| Digital settings: | Temperature, rotations, vacuum |
| Gradient settings: | Temperature, pressure |
| Temperature unit selection: | °C, °K |
| Pressure units selections: | hPa, Torr |
| Cooler condensation size: | 1200 sq cm (double spiral) |
| Switched vacuum pump: | output max 650 VA, input max. 2000 VA |
| Power supply: | 230 V ±10%, 50/60 Hz |
| Power input: | max. 2000 W (excluding vacuum pump) |
| Dimensions in mm (WxHxD): | 650 x 900 x 360 (incl. glass) |
| Net weight: | approx 20 kg |
Ordering information
| Code | Description |
|---|---|
| BOE 8090020 | BOECO Rotary Evaporator RVO 400 SD, with heating bath, motorized lift, built-in vacuum controller, digital measuring and control system with vertical condenser, 230 V |
| BOE 8090030 | BOECO Rotary Evaporator RVO 400 SD, with heating bath, motorized lift, built-in vacuum controller, digital measuring and control system with diagonal condenser, 230 V |
Accessories
| Code | Description |
|---|---|
| BOE 8090005 | Safety bath cover, Plexiglass |
| BOE 8090006 | Wireless remote controller |
| BOE 8090007 | PC-based evaporation control software |
Source: BOECO Germany – https://www.boeco.com/boeco-rotary-evaporator-rvo-400-sd&sk=315
Specifications for BOECO Rotary Evaporator RVO 400 SD
| Condenser | Vertical condenser or Diagonal condenser |
