Zebron ZB-1HT GC Columns
Robust Results Up to 430 ºC
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Robust Results Up to 430 ºC
100% dimethylpolysiloxane with high temperature stability up to 430 °C for non-polar compounds
Key Features
- First non-metal columns stable to 430 °C
- Provides true boiling point separation for hydrocarbon distillation methods
- Longer lifetime with rugged high temperature, polyimide coated, fused silica tubing
- Low activity, provides good peak shape for acidic and basic samples
- Provides robust column performance for high temperature bake outs
Recommended Use
Rugged, high-temperature stability (up to 430 °C) for non-polar compounds for high boilers, contaminants, carry-overs, and high-temp bakeouts
Specifications
| Phase classification | High Temperature |
| Stationary phase | 100 % Dimethylpolysiloxane (high-temperature) |
| USP phase | G1, G2, G9, G38 |
| Temperature limits | -60 to 430 °C |
| Available lengths (m) | 5, 10, 15, 20, 30 |
| Available internal diameters (mm) | 0.18, 0.25, 0.32, 0.53 |
| Available film thicknesses (µm) | 0.1, 0.15, 0.18, 0.25 |
Specification source: Phenomenex site + GC catalogue 2020-21
Specifications for Zebron ZB-1HT GC Columns
| GC Length (m) | 5 or 10 or 15 or 20 or 30 or 60 or N/A |
| GC Internal Diameter (mm) | 0.18 or 0.25 or 0.53 or 0.32 or N/A |
| GC Film Thickness (µm) | 0.18 or 0.1 or 0.88 or 0.15 or 0.25 or N/A |
| GC Format | Capillary Column or 5-inch Cage |
| GC Option | Standard or Custom or w/ GUARDIAN 5 m, Custom or w/ GUARDIAN 5 m or Reverse Winding |
| Manufacturer | Phenomenex |
| GC Phase | ZB-1HT |
