Cleaver Scientific EV3xxxH Series High Voltage Power Supply
Ultra high voltage electrophoresis power supplies up to 6000 V, 300 W, with a dedicated low-current IEF mode, 4 output pairs and USB data logging.
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Cleaver Scientific EV3xxxH Series High Voltage Power Supply
The front panel and graphical display are designed for ease of use. The display provides all useful information during runs and shows on-screen help to guide the user in setting up the power supply. In Simple Mode you only have to set the power supply to the desired parameters and press run.
The series has firmware upgrade capability so future improvements and features are always available, and continuous logging combined with a real time clock makes it possible to review previous runs, including any down-time caused by mains power failures. The complete EV series holds its voltage constant at low currents without problem and keeps functioning at low and high temperatures.
Running modes — Simple Mode: set voltage, current, power and time for a routine run. 9×9 Method Programming Mode: up to 9 different programs, each with 9 steps, stored in non-volatile memory; each step can recall a next one, giving a flexible multi-step function for special techniques, and parameters of the running step can be changed temporarily without interrupting the run. Voltage Ramp Mode: a linear voltage gradient for any step, provided the limiting current or power is not attained. Timer Mode: timer or volt-hour controlled operation stops the run automatically and sounds an alarm. Each model has constant voltage, constant current and constant power capability with automatic cross-over, and shows which parameter is being held constant. Automatic recovery after power failure, password protection and data logging are standard.
Safety features — ground leakage detection protects from potential shock hazard when a leakage path is detected; overload protection gives full protection against any overload condition including accidental short circuit of the output; smooth voltage rise prevents high voltage from appearing suddenly at the outputs, increasing smoothly up to the pre-set limits; no-load detection prevents errors such as a bad or dangling connection; and the optically isolated USB connection prevents any high voltage on the communication lines.
At a glance
- Ultra high voltage power supplies up to 6000 V
- Various running modes including a dedicated low-current IEF mode
- On-screen help in 4 languages
- Password protection
- Data logging with real time clock
- Firmware upgradeable via USB
- Comprehensive safety features
- 4 pairs of outputs
Specifications
| Specification | EV3330 | EV3620 |
|---|---|---|
| Maximum Voltage (V) | 3000 | 6000 |
| Maximum Current (mA) | 200 | 100 |
| Maximum Power (W) | 300 | 300 |
| Minimum Load Resistance | 600 Ω | 1200 Ω |
| Number of Output Pairs | 4 (4 mm sockets) | 4 (2 mm sockets) |
| Operating Modes | Constant Parameter, Programmable 9 Step Programme | Constant Parameter, Programmable 9 Step Programme |
| Display | LCD, 2 x 16 characters | LCD, 2 x 16 characters |
| Resolution | 1 V, 1 mA, 1 W | 1 V, 1 mA, 1 W |
| Timer | 0…99:59 h | 0…99:59 h |
| Control Interface | USB | USB |
| Password Protection | Yes | Yes |
| No Load / Overload / Ground Leakage Detection | Yes | Yes |
| Input Voltage | 230 V (110 V on “$” codes) | 230 V (110 V on “$” codes) |
| Operating Temperature | 0…40 °C | 0…40 °C |
| Operating Environment | 0…95%, non-condensing | 0…95%, non-condensing |
| Compliance Marks | CE | CE |
| Unit Dimensions (cm) | 31 x 26 x 13 | 31 x 26 x 13 |
| Weight (kg) | 10 | 10 |
Ordering Information
| Code | Output | Mains input |
|---|---|---|
| EV3330 | 3000 V / 200 mA / 300 W | 230 V |
| EV3330$ | 3000 V / 200 mA / 300 W | 110 V |
| EV3620 | 6000 V / 100 mA / 300 W | 230 V |
| EV3620$ | 6000 V / 100 mA / 300 W | 110 V |
Codes ending in “$” denote the 110 V mains version of the same unit.
Specifications for Cleaver Scientific EV3xxxH Series High Voltage Power Supply
| Manufacturer | Cleaver Scientific |
